Nominal voltage 51.2V
Nominal Capacity 50Ah
Nominal energy 2560Wh
Life Cycles 6000 Cycles (25?, 80% DOD)
Recommended Charge Voltage 57.6V
Recommended Charge Current 20.0A
End of discharge voltage 44.0V
Standard method Charge 10.0A
Discharge 25.0A
Maximum continuous current Charge 50.0A
Discharge 50.0A
BMS Cut-Off Voltage Charge >58.4 V (3.65V/Cell)
Discharge <32.0V (2s) (2.0V/Cell)
Temperature Charge 0 ~ 45?
Discharge -20 ~ 55 ?
Storage Temperature -5~35?
Shipment voltage ≥51.2V
Module Parallel Up to 4 units
Communication CAN2.0/RS232/RS485
Case Material SPPC
Dimension (L x W x H) 525 x 350 x 135 mm
Approx. Weight 23 kg
|
