DC Voltage (V) 200mV/2V/20V/200V/1000V ±(0.1%+8)
AC Voltage (V) 2V/20V/200V/1000V ±(0.8%+40)
DC Current (A) 200μA/2000μA/20mA/200mA/10A ± (0.2%+20)
AC Current (A) 200μA/2000μA/20mA/200mA/10A ± (1%+15)
Resistance (Ω) 200Ω/2KΩ/20KΩ/200KΩ/2MΩ/20MΩ ±(0.5%+20)
Capacitance (F) 20nF/200nF/2μF/20μF/200μF/2mF/20mF ±(1.5%+20)
Frequency (Hz) 20Hz-200MHz ±(0.1%+15)
Features
Display Count 19999
Auto Range √
True RMS √
Bandwidth (Hz） 100KHz √
Duty Cycle 10% ～ 90% ±(1%+30)
Diode √
Auto Power Off √
Continuity Buzzer √
Low Battery Indication √
Data Hold √
Relative Mode √
MAX/MIN √
USB Interface √
Double Backlight √
Analogue Bar Graph √
Full Icon Display √
Setup √
Input Impedance for DCV DC 200mV: Around 2.5GΩ，All Other Range： 10MΩ √
4 - 20mA Loop 0～100%
Fused 10 A √
Current Measurement Alarm √
Voltage & Current AC+DC Measurement √
General Characteristic
Power 9V Battery（6F22)
LCD Size 73mm X 50 mm
Product Color Red and Grey
Product Net Weight 384g
Product Size 200mm X 93mm X 40 mm
Standard Accessories Battery, Test Lead, Alligator Clip, Test Clip, USB Interface Cable,PC Software CD,Carrying Bag, English Manual
|
