DC Voltage (V) 400mV/4V/40V/400V/1000V ±(0.025%+5)
AC Voltage (V) 4V/40V/400V/1000V ±(0.4%+30)
DC Current (A) 400μA/4000μA/40mA/400mA/10A ± (0.1%+15)
AC Current (A) 400μA/4000μA/40mA/400mA/10A ± (0.7%+15)
Resistance (Ω) 400Ω/4KΩ/40KΩ/400KΩ/4MΩ/40MΩ ±(0.3%+8)
Capacitance (F) 40nF/400nF/4μF/40μF/400μF/4mF/40mF ±(1%+20)
Frequency (Hz) 40Hz-400MHz ±(0.01%+8)
Temperature (°C) -40 °C ～ 1000°C ±(1%+30)
Temperature (°F) -40°F～1832°F ±(1.5%+50)
Features
Display Count 39999
Auto Range √
True RMS √
Bandwidth (Hz） 100KHz √
Duty Cycle 10% ～ 90% ±(1%+30)
Diode √
Auto Power Off √
Continuity Buzzer √
Low Battery Indication √
Data Hold √
Relative Mode √
MAX/MIN √
Data Logging 9999
USB Interface √
Double Backlight √
Analogue Bar Graph √
Full Icon Display √
Setup √
Input Impedance for DCV DC 400mV: Around 2.5GΩ，All Other Range： 10MΩ √
4 - 20mA Loop 0～100% ±(1%+50)
Fused 10 A √
Current Measurement Alarm √
Voltage & Current AC+DC Measurement √
General Characteristic
Power 9V Battery（6F22)
LCD Size 73mm X 50 mm
Product Color Red and Grey
Product Net Weight 384g
Product Size 200mm X 93mm X 40 mm
Standard Accessories Battery, Test Lead, Alligator Clip, Test Clip, USB Interface Cable,PC Software CDe,Carrying Bag, Point Contact Temperature Probe, English Manual
|
